Elixir clustering using Postgres

2024-01-09

6 minute read

Elixir offers a powerful feature by allowing multiple nodes to communicate between them without extra services in the middle, reducing the overall complexity of your system.

However, when it comes to connecting the servers, there seems to be a barrier of entry that many people encounter, including ourselves, on how to provide the name discovery required to connect said servers. We have released our approach to solving this problem by open-sourcing libcluster Postgres Strategy and today, we explore the motivations behind its creation and the methodologies employed in its development.

Why do we need a distributed Erlang Cluster?

At Supabase, we use clustering in all of our Elixir projects which include Logflare, Supavisor and Realtime. With multiple servers connected, we can load shed, create globally distributed services, and provide the best service to our customers so we’re closer to them geographically and to their instances, reducing overall latency.

To achieve a connected cluster, we wanted to be as cloud-agnostic as possible. This makes our self-hosting options more accessible. We don’t want to introduce extra services to solve this single issue - Postgres is the logical way to achieve it.

The other piece of the puzzle was already built by the Erlang community being the defacto library to facilitate the creation of connected Elixir servers: libcluster.

What is libcluster?

libcluster is the go-to package for connecting multiple BEAM instances and setting up healing strategies. libcluster provides out-of-the-box strategies and it allows users to define their own strategies by implementing a simple behavior that defines cluster formation and healing according to the supporting service you want to use.

How did we use Postgres?

Postgres provides an event system using two commands: NOTIFY and LISTEN so we can use them to propagate events within our Postgres instance.

To use these features, you can use psql itself or any other Postgres client. Start by listening on a specific channel, and then notify to receive a payload.


_10
postgres=# LISTEN channel;
_10
LISTEN
_10
postgres=# NOTIFY channel, 'payload';
_10
NOTIFY
_10
Asynchronous notification "channel" with payload "payload" received from server process with PID 326.

Now we can replicate the same behavior in Elixir and Postgrex within IEx (Elixir's interactive shell).


_16
Mix.install([{:postgrex, "~> 0.17.3"}])
_16
config = [
_16
hostname: "localhost",
_16
username: "postgres",
_16
password: "postgres",
_16
database: "postgres",
_16
port: 5432
_16
]
_16
{:ok, db_notification_pid} = Postgrex.Notifications.start_link(config)
_16
Postgrex.Notifications.listen!(db_notification_pid, "channel")
_16
{:ok, db_conn_pid} = Postgrex.start_link(config)
_16
Postgrex.query!(db_conn_pid, "NOTIFY channel, 'payload'", [])
_16
_16
receive do msg -> IO.inspect(msg) end
_16
# Mailbox will have a message with the following content:
_16
# {:notification, #PID<0.223.0>, #Reference<0.57446457.3896770561.212335>, "channel", "test"}

Building the strategy

Using the libcluster Strategy behavior, inspired by this GitHub repository and knowing how NOTIFY/LISTEN works, implementing a strategy becomes straightforward:

  1. We send a NOTIFY to a channel with our node() address to a configured channel

_21
# lib/cluster/strategy/postgres.ex:52
_21
def handle_continue(:connect, state) do
_21
with {:ok, conn} <- Postgrex.start_link(state.meta.opts.()),
_21
{:ok, conn_notif} <- Postgrex.Notifications.start_link(state.meta.opts.()),
_21
{_, _} <- Postgrex.Notifications.listen(conn_notif, state.config[:channel_name]) do
_21
Logger.info(state.topology, "Connected to Postgres database")
_21
_21
meta = %{
_21
state.meta
_21
| conn: conn,
_21
conn_notif: conn_notif,
_21
heartbeat_ref: heartbeat(0)
_21
}
_21
_21
{:noreply, put_in(state.meta, meta)}
_21
else
_21
reason ->
_21
Logger.error(state.topology, "Failed to connect to Postgres: #{inspect(reason)}")
_21
{:noreply, state}
_21
end
_21
end

  1. We actively listen for new {:notification, pid, reference, channel, payload} messages and connect to the node received in the payload

_16
# lib/cluster/strategy/postgres.ex:80
_16
def handle_info({:notification, _, _, _, node}, state) do
_16
node = String.to_atom(node)
_16
_16
if node != node() do
_16
topology = state.topology
_16
Logger.debug(topology, "Trying to connect to node: #{node}")
_16
_16
case Strategy.connect_nodes(topology, state.connect, state.list_nodes, [node]) do
_16
:ok -> Logger.debug(topology, "Connected to node: #{node}")
_16
{:error, _} -> Logger.error(topology, "Failed to connect to node: #{node}")
_16
end
_16
end
_16
_16
{:noreply, state}
_16
end

  1. Finally, we configure a heartbeat that is similar to the first message sent for cluster formation so libcluster is capable of heal if need be

_10
# lib/cluster/strategy/postgres.ex:73
_10
def handle_info(:heartbeat, state) do
_10
Process.cancel_timer(state.meta.heartbeat_ref)
_10
Postgrex.query(state.meta.conn, "NOTIFY #{state.config[:channel_name]}, '#{node()}'", [])
_10
ref = heartbeat(state.config[:heartbeat_interval])
_10
{:noreply, put_in(state.meta.heartbeat_ref, ref)}
_10
end

These three simple steps allow us to connect as many nodes as needed, regardless of the cloud provider, by utilizing something that most projects already have: a Postgres connection.

Conclusion

In this post, we have described our approach to connecting multiple nodes in Elixir using Postgres. We have also made this strategy available for anyone to use. Please check the code at github.com/supabase/libcluster_postgres

A special thank you to @gotbones for creating libcluster and @kevinbuch_ for the original inspiration for this strategy.
